BIOSTAR H61MGV3

Model

Brand

BIOSTAR

Model

H61MGV3

Supported CPU

CPU Socket Type

LGA 1155

CPU Type

Core i7 / i5 / i3 / Pentium (LGA1155)

Chipsets

Chipset

Intel H61

Onboard Video

Onboard Video Chipset

Supported only by CPU with integrated graphic

Memory

Number of Memory Slots

2×240pin

Memory Standard

DDR3 1600/1333/1066

Maximum Memory Supported

16GB

Channel Supported

Dual Channel

Expansion Slots

PCI Express 3.0 x16

1 x PCI Express 3.0 x16

PCI Express x1

1 x PCI Express x1

Storage Devices

SATA 3Gb/s

4 x SATA 3Gb/s

Onboard Audio

Audio Chipset

VIA VT1705CF

Audio Channels

6 Channels

Onboard LAN

LAN Chipset

Realtek RTL8111G

Max LAN Speed

10/100/1000Mbps

Rear Panel Ports

PS/2

2

Video Ports

D-Sub

USB 1.1/2.0

4 x USB 2.0

Audio Ports

3 Ports

Internal I/O Connectors

Onboard USB

4 x USB 2.0

Other Connectors

1 x Front Audio Header
1 x Front Panel Header
1 x CPU FAN Header
1 x System FAN Header
1 x Serial Header

Physical Spec

Form Factor

Micro ATX

Dimensions (W x L)

7.48″ x 6.69″

Features

Features

Socket LGA 1155

Supported the Intel 3rd and 2nd generation Core i7/ i5/ i3 processors in the 1155 package

Supported 2 DIMM of DDR3 1600/1333/1066MHz

Supports BIO-Remote 2 Technology
