Spesifikasi
- Display System : 3 LCD system
- Display device
Size of effective display area : 0.63” (16 mm) x 3 LCD Panel, Aspect ratio: 4:3
Number of pixels : 2,359,296 (1024×768 x 3) pixels - Projection lens
Focus : Manual
Zoom – Powered/Manual : Manual
Zoom – Ratio : Approx. x 1.2
Throw Ratio : 1.47:1 to 1.77:1 - Light source
Type : Ultra high pressure mercury lamp
Wattage : 210 W type
Screen size
Screen size : 30” to 300” (0.76 m to 7.62 m)(measured diagonally
Light output
Lamp mode: High : 2300 lm
Lamp mode: Standard : 1800 lm
Lamp mode: Low : 1500 l - Contrast ratio (full white / full black)
Contrast ratio : 3000:1
Speaker : 1 W x 1 (monaural) - Displayable scanning frequency
Horizontal : 19 kHz to 92 kHz
Vertical : 48 Hz to 92 Hz - Display resolution
Computer signal input : Maximum display resolution: UXGA 1600 x 1200 dots*3
Video signal input : NTSC, PAL, SECAM,480/60i, 576/50i, 480/60p, 576/50p, 720/60p, 720/50p, 1080/60i, 1080/50i
The following items are available for digital signal (HDMI input) only; 1080/60P, 1080/50p
Color system : NTSC3.58, PAL, SECAM, NTSC4.43, PAL-M, PAL-N - Keystone correction (Max.) : +/- 30 degrees
- OSD language : 23-language (English, French, German, Italian, Spanish, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Dutch, Norwegian, Swedish, Thai, Arabic ,Turkish, Polish, Vietnamese, Farsi,
- Finnish, Indonesian, Hungarian)
INPUT OUTPUT (Computer/Video/Control)
INPUT A : RGB / Y PB PR input connector: Mini D-sub 15-pin (female)/Audio input connector: Stereo mini jack (shared with VIDEO IN)
INPUT B : HDMI input connector: HDMI 19-pin, HDCP support
VIDEO IN : Video input connector: Pin jack - Audio input connector: Shared with INPUT A
- Acoustic noise : < 35 dB
- Operating temperature / Operating humidity : 0°C to 35°C (32°F to 95°F) / 20% to 80%（no condensation)
- Storage temperature / Storage humidity : -10°C to +60°C (14°F to +140°F) / 20% to 80%（no condensation)
- Power requirements
AC 100 V to 240 V, 2.9 A to 1.2 A, 50 Hz / 60 Hz - Power Consumption (Standby Mode)
AC 100 V to 120 V : 987 BTU/h
AC 220 V to 240 V : 943 BTU/h - Dimensions (W x H x D) : Approx. 315 x 75 x 230.5 mm (12 13/32 X 2 15/16 X 9 1/16 inches)
- Mass : Approx. 2.5 kg (5.5 lb)
