| Chipset | Intel B150 |
| CPU SUPPORT | Intel® Core™ i7 LGA 1151 Processor Intel® Core™ i5 LGA 1151 Processor Intel® Core™ i3 LGA 1151 Processor Intel® Pentium® LGA 1151 Processor Intel® Celeron® LGA 1151 Processor Maximum CPU TDP (Thermal Design Power) : 95Watt |
| MEMORY | Support Dual Channel DDR4 2133/ 1866 MHz 2 x DDR4 DIMM Memory Slot Max. Supports up to 32GB Memory |
| EXPANSION SLOT | 1 x PCI-E x16 3.0 Slot 2 x PCI-E x1 3.0 Slot |
| STORAGE | 4 x SATA3 Connector |
| USB | 4 x USB 3.0 Port 1 x USB 3.0 Header 2 x USB 2.0 Port 2 x USB 2.0 Header |
| LAN | Realtek RTL8111H – 10/100/1000 Controller Support Super LAN Surge Protection |
| INTEGRATED VIDEO | By CPU model Supports DX12 Supports HDCP |
| CODEC | Realtek ALC887 8-Channel HD Audio Support Biostar Hi-Fi |
| REAR I/O | 1 x PS/2 Mouse 1 x PS/2 Keyboard 4 x USB 3.0 Port 2 x USB 2.0 Port 1 x DVI-D Connector, resolution up to 1920 x 1200 @60Hz 1 x VGA Port, resolution up to 1920 x 1200 @60Hz 1 x RJ-45 Port 3 x Audio Connector |
| INTERNAL I/O | 1 x USB 3.0 Header 2 x USB 2.0 Header 4 x SATA3 6Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Header 1 x System Fan Header 1 x Serial Header |
| H/W MONITORING | CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control System Voltage Monitoring |
| DIMENSION | Micro ATX Form Factor Dimension: 22.6cm x 18.5cm ( W x L ) |
| OS SUPPORT | Support Windows 7 / 8.1(x64) / 10(x64) |
| BUNDLE SOFTWARE | BullGuard Smart Ear headphone Utility BIO-Remote2 Smart Speed LAN |
| ACCESSORIES | 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide |
| FEATURES | Supports PURO Hi-Fi(Rear) Supports 100% Solid capacitor Supports Charger Booster Supports BIOS Online Update |
